Scanner

Paper documents reach the archive through the scanning workstation. To match a scanned sheet to the right SAP document, ECM-Connect works with barcodes: the document carries a barcode, and the scanned file is matched and linked through it.

What is this for?

• Get paper documents into the archive without manual assignment.
• Establish the link between paper and SAP document through the barcode.
• Control retention and reuse of the barcodes.

How to set it up

1. Enable the scan client in the document link.
2. Use auto barcode to decide whether the barcode is generated automatically and must barcode whether it is mandatory.
3. Define the archive field for the barcode via the ECMBARCODEFIELD setting.
4. Set the retention period via ECMBARCODERETENSION (in months).
5. Print the documents – the barcode is applied –, scan them and file them.

Related settings

Code	Name	Type	Default
ECMBARCODEFIELD	ECM field for barcode	Text	BARCODE
ECMBARCODESTATUS	ECM field for barcode status	Text	BARCODE_SENT
ECMBARCODERETENSION	Retention time for barcodes in months	Integer	3
ECMBARCODEDELETE	Delete barcodes after retention time	Yes/No	Y
ECMBARCODEREUSE	Reuse external barcode	Yes/No	Y

Every other setting is listed in the full reference.
